CLGR® Pulley with Hinged Side Plate Swivel Hook

Name: CLGR® Pulley with Hinged Side Plate Swivel Hook
Brand: CLGR®

CLGR® Pulley with Hinged Side Plate Swivel Hook, also known as Opening Forestry Pulley with Swivel Hook, and Rope Roller.

This openable forestry pulley features a swivel hook for quick and secure anchoring, making it easy to position and attach in the field.

Constructed from galvanized steel with a robust bearing, it delivers reliable strength and smooth rope operation in demanding forestry conditions.

The openable side plate enables fast rope insertion without threading — saving time during setup.

Important: This pulley is designed for pulling and positioning applications. It must not be used for lifting or overhead suspension.

To Get A Quote >

CLGR® Pulley with Hinged Side Plate Swivel Hook

Pulley with Hinged Side Plate Swivel Hook

 

Overview of CLGR® Pulley with Hinged Side Plate Swivel Hook

Material	Super Carbon Steel
Craft	Forged
Surface Finished	Red Painted
Size	140mm, 180mm, 220mm

Specification of CLGR® Pulley with Hinged Side Plate Swivel Hook

No.	Size	W.L.L	Dia of Rope	Net Weight
No.	mm	ton	mm	kg
CRWST118140	140	2	10	6.5
CRWST118180	180	3.2	12	12
CRWST118220	220	5	16	23
