CLGR® JIS Ship Wooden Block With Shackle Single Sheave

Name: CLGR® JIS Ship Wooden Block With Shackle Single Sheave
Brand: CLGR®

CLGR® JIS Ship Wooden Block With Shackle Single Sheave, also known as JIS Wooden Block With Shackle.

Made of high quality wood and fitted with a hot-dip galvanized steel shackle, this wooden block with shackle minimizes line chafing while providing a smooth 180° rope redirection.

It is designed to work in conjunction with ropes, providing mechanical advantage and changing the direction of force. This allows crew members to handle heavy loads with less effort.

To Get A Quote >

Overview of CLGR® JIS Ship Wooden Block With Shackle Single Sheave

Brand	China CLGR®
Material	Carbon steel/Wood
Craft	Machining/Stamping/Forging/Hot Dipped Galvanized
Size	140inch,180inch, 200inch, 220inch, 240inch
Sheave	Single Sheave

Specification of CLGR® JIS Ship Wooden Block With Shackle Single Sheave

Drawing of CLGR® JIS Ship Wooden Block With Shackle Single Sheave

Part No.	Size/in	SWL/TON	Diam	∅	L	A	B	Weight(KG)
CRWSSPS-D14	140	0.18	14mm	91	280	112	69	2.32
CRWSSPS-D18	180	0.29	18mm	117	367	144	82	3.62
CRWSSPS-D20	200	0.35	20mm	130	398	160	89	4.73
CRWSSPS-D22	220	0.42	22mm	143	402	176	97	6.48
CRWSSPS-D24	240	0.5	24mm	156	445	192	103	8.44
