CLGR® Carbon Steel Pear Link, also known as Carbon Pear Shaped Links, Pear Shape Sling Link, Pear Shaped Weldless Sling Link, and Galvanized Pear Sling Link.
Drop forged from carbon steel and quenched & tempered, the Carbon Pear Shaped Links provide high tensile strength, excellent wear resistance, and reliable toughness for demanding load-bearing applications.
Brand | CLGR® |
Material | Carbon Steel |
Processing | Drop Forged / Quenched and Tempered |
Finish | Zinc plated, Hot dipped galvanized, Self-colored |
Size | 3/8", 1/2",5/8",3/4",7/8", 1", 1-1/4", 1-3/8", 1-1/2", 1-3/4", 2" |
Country of Origin | China |
Part No. | Diameter | Inside | Inside Width | Each | W.L.L (Single Pull) | |
Small end | Large end | Carbon | ||||
Carbon Steel | inch | inch | inch | inch | lbs | lbs |
CRPL01C | 3/8" | 2.25 | 0.75 | 1.5 | 0.23 | 1600 |
CRPL02C | 1/2" | 3 | 1 | 2 | 0.55 | 2900 |
CRPL03C | 5/8" | 3.75 | 1.25 | 2.5 | 1.1 | 4200 |
CRPL04C | 3/4" | 4.5 | 1.5 | 3 | 1.95 | 6000 |
CRPL05C | 7/8" | 5.25 | 1.75 | 3.5 | 2.78 | 8300 |
CRPL06C | 1" | 6 | 2 | 4 | 4.3 | 10800 |
CRPL07C | 1-1/4" | 7.75 | 2.5 | 5 | 8.5 | 16750 |
CRPL08C | 1-3/8" | 8.25 | 2.75 | 5.5 | 11.5 | 20500 |
CRPL09C | 1-1/2" | 9 | 3 | 6 | 15.25 | * |
CRPL10C | 1-3/4" | 10.5 | 3.5 | 7 | 22.5 | * |
CRPL11C | 2" | 12 | 4 | 8 | 34 | * |
