CLGR® 6X7+IWS Stainless Steel Wire Rope

Name: CLGR® 6X7+IWS Stainless Steel Wire Rope
Brand: CLGR®

CLGR® 6X7+IWS Stainless Steel Wire Rope consists of six strands of seven wires, is a flexible and relatively simple construction, providing exceptional abrasion resistance.

It is suitable for a variety of lifting, pulling, and tensioning applications.

To Get A Quote >

Overview of CLGR® 6X7+IWS Stainless Steel Wire Rope

Brand	CLGR®
Construction	6x7+IWS/IWRC
Material	Stainless Steel
Surface Finish	Polished
Characteristics	Excellent abrasion resistance; less bending fatigue resistance
Country of Origin	China

Specifications of CLGR® 6X7+IWS Stainless Steel Wire Rope

Part No.	Nominal Dia.	Dia. Tolerance	MBL	Approx Weight
Part No.	mm	mm	KN	Kg/100m
6x7IWRC01S	0.45	＋0.09	0.142	0.08
6x7IWRC02S	0.5		0.176	0.12
6x7IWRC03S	0.6		0.253	0.15
6x7IWRC04S	0.7		0.345	0.2
6x7IWRC05S	0.8		0.461	0.26
6x7IWRC06S	0.9		0.539	0.32
6x7IWRC07S	1	＋0.15	0.637	0.4
6x7IWRC08S	1.2		1.2	0.65
6x7IWRC09S	1.5		1.67	0.93
6x7IWRC10S	1.6	＋0.2	2.15	1.2
6x7IWRC11S	1.8		2 25	1.35
6x7IWRC12S	2		2. 94	1.65
6x7IWRC13S	2.4		4.1	2.4
6x7IWRC14S	3	＋0.3	6.37	3.7
6x7IWRC15S	3.2	＋0.3	7.15	4.2
6x7IWRC16S	3.5	＋0.4	7.64	5.1
6x7IWRC17S	4		9.51	6.5
6x7IWRC18S	4.5		12.1	8.3
6x7IWRC19S	5		14.7	10.5
6x7IWRC20S	6	＋0.6	18.6	15.1
6x7IWRC21S	8	＋0.6	40.6	26.6
