CLGR® Stainless Steel DIN 766 Short Link Chain

Name: CLGR® Stainless Steel DIN 766 Short Link Chain
Brand: CLGR®

CLGR® DIN 766 Short Link Chain, made of stainless steel 316, excellent for areas of extreme corrosion, such as a saltwater environment.

Designed and dimensioned according to DIN 766, this high-quality stainless steel short link chain is perfect for use in exterior and corrosive environments, and can be purchased in multiples of 1 meter.

Stainless steel chain in A4, AISI 316 grade, come in various sizes: 2mm, 3mm, 4mm, 5mm, 6mm, 7mm, 8mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 18mm,19mm, 20mm, 22mm, 23mm, 26mm, 28mm, 30mm,32mm.

To Get A Quote >

CLGR® Stainless Steel DIN 766 Short Link Chain

Overview of CLGR® Stainless Steel DIN 766 Short Link Chain

Brand	CLGR®
Size	2mm, 3mm, 4mm, 5mm, 6mm, 7mm, 8mm, 10mm, 11mm, 12mm, 13mm, 14mm, 16mm,18mm,19mm, 20mm,22mm,23mm,26mm,28mm,30mm,32mm
Standard	DIN 766
Material	Stainless Steel
Processing	Welded
Surface Finish	Highly Polishing
Note	NOT FOR OVERLOAD LIFTING
Application	Lifting and connecting, Wire rope fittings, Chain fittings

Specifications of CLGR® Stainless Steel DIN 766 Short Link Chain

Part No.	SIZE		INSIDE LENGTH			OUTSIDE WIDTH		LENGTH PER 11LINKS			WEIGHT PER M
Part No.	MM	+/-MM	MM	+MM	-MM	MM	MM	MM	+MM	-MM	KG
CRSSSLC76602	2	0.2	12	0.2	0.2	3.5	7.5	132	1	0.5	0.07
CRSSSLC76603	3	0.2	16	0.2	0.2	4.2	11	176	1.4	0.7	0.16
CRSSSLC76604	4	0.2	16	0.3	0.2	5	13.7	176	2.1	1.1	0.32
CRSSSLC76605	5	0.2	18.5	0.4	0.2	6	17	203.5	2.4	1.2	0.5
CRSSSLC76606	6	0.2	18.5	0.4	0.2	7.2	20.2	203.5	2.4	1.2	0.8
CRSSSLC76607	7	0.3	22	0.4	0.2	8.4	23.8	242	3	1.4	1.1
CRSSSLC76608	8	0.3	24	0.4	0.2	9.6	27.2	264	3.2	1.5	1.4
CRSSSLC76609	9	0.4	27	0.5	0.3	10.8	30.6	297	3.6	1.8	1.8
CRSSSLC76610	10	0.4	28	0.5	0.3	12	34	308	3.7	1.9	2.2
CRSSSLC76611	11	0.4	31	0.5	0.3	13.2	37.4	341	4	2	2.7
CRSSSLC76612	12	0.3	36	0.6	0.3	14.4	40.8	396	4.4	2.2	3.1
CRSSSLC76613	13	0.5	36	0.6	0.3	15.6	44.2	396	4.6	2.4	3.8
CRSSSLC76614	14	0.6	41	0.7	0.4	16.8	47.6	451	5.4	2.7	4.4
CRSSSLC76616	16	0.6	45	0.8	0.4	19.2	54.4	495	6	3	5.7
CRSSSLC76618	18	0.9	50	0.8	0.4	21.6	61.2	550	6.6	3.3	7.3
CRSSSLC76619	19	0.4	53	0.9	0.4	22.8	64.6	583	7	3.7	7.97
CRSSSLC76620	20	1	56	1	0.5	24	68	616	7.4	3.7	9
CRSSSLC76622	22	1.1	62	1.1	0.5	26.4	75	682	8.0	4.0	11.0
CRSSSLC76623	23	1.2	64	1.1	0.5	27.6	78.2	704	8.4	4.2	12
CRSSSLC76626	26	1.3	73	1.2	0.6	31.2	88.4	803	9.6	4.8	15
CRSSSLC76628	28	1.4	78	1.3	0.65	33.8	95.2	858	10.2	5.1	18
CRSSSLC76630	30	1.5	84	1.4	0.7	41	102	924	11	5.5	19.5
CRSSSLC76632	32	1.6	90	1.5	0.75	43	108.8	990	11.8	5.9	23

CLGR® Are Expecting Your Inquiry!

We design, manufacture and distribute products and provide services for lifting and material handling applications, the construction metal industry, the trawl industry and the yacht accessories industry.
