The CLGR® Electric-hydraulic Chain Cutter, also known as Self-contained/ Portable Electro-hydraulic Chain Cutter.
Electric-hydraulic Chain Cutter is suitable for chains of different diameters, this one is for G80 chain 10-26mm, G100 chain 10-19mm.
The CLGR® electro-hydraulic chain cutters are ideal for daily use in the chain processing industry, as our high-quality construction steel cutters can reliably and effectively cut chains of different diameters—specifically up to quality Grade 8 or Grade 10.
Boasting robust workmanship that guarantees a long service life for these professional products, the electro-hydraulic chain cutters are highly suitable for building and industrial works.
With small dimensions, the electro-hydraulic chain cutters can easily carry to any places, while being equipped with a protective cover and additional protective devices to ensure optimal safety during operation.
Brand | CLGR® | |
Part No. | CRC13C | CRC26C |
Cutting capacity | Ø13 mm (G 30) Ø6-13 mm (G 80) Ø6-10 mm (G 100) | Ø13-26 mm (G 30) Ø10-26 mm (G 80) ø10-19 mm (G 100) |
Cutting force | 151.9kN (15.5 ton) | 418.46 kN (42.7 ton) |
Power supply | - | Mains |
Motor | 220V: 1200W - 50HZ | 220V/110V: 1800 W |
Cylinder | Double Acting | |
Weight | 15.5kg | 36.4kg |
Overall Size | Approx. 540*140*245mm | Approx. 700 x 192 x 321 mm |
1. Connection: Connect the electro - hydraulic chain cutter to a suitable power source. Ensure that all connections are secure and that the power supply meets the required specifications.
2. Preparation: Before cutting, inspect the chain to be cut for any signs of damage or defects. Place the chain in the cutting area of the machine, making sure it is properly aligned.
3. Cutting: Activate the cutter, and the hydraulic system will engage, applying the cutting force to the chain. Once the cut is complete, release the cutter and remove the cut chain.
