CLGR® Bench Swager 1/16 inch to 3/16 inch Drop Forged

Name: CLGR® Bench Swager 1/16 inch to 3/16 inch Drop Forged
Brand: CLGR®

The Bench Swager also known as Bench Type Hand Swager, Bench Mount Swager, some customers also called it Bench Mounted Swaging Tool, Heavy-Duty Bench Mount Swager, Bench Swaging Crimping Tool and Tyler Tool Bench Swager/Cutter.

The Bench Swager is a bench-mounted all-in-one tool designed for both swaging and cutting operations, enabling one-handed use with vibration-damping rubber grips and forged jaws.

Equipped with a rubber handle for optimal gripping and a built-in wire rope cutter, the CLGR® Bench Swager can efficiently swage ferrules (including aluminum, copper, and zinc-plated copper oval and stop sleeves) and cut cables—all with one hand.

The shock-proof design of the Bench Swager, paired with ergonomic handles that eliminate vibration, ensures the tool remains usable over extended timeframes, providing both convenience and comfort during prolonged use.

About The Later Maintenance: Clean and lubricate all moving parts regularly; Keep all bolts tight; Keep your swager properly adjusted.

To Get A Quote >

clgr-bench-swager-1-16-inch-to-3-16-inch-drop-forged-design

Overview of CLGR® Bench Swager 1/16 inch to 3/16 inch Drop Forged

Brand	CLGR®
Material	Super Alloy Steel
Connection Style	Manual Swaging
Processing	Heat Treatment
Components	The bench swager tool kit comes with a bolt cutter, a crimper, and a cable cutter head.
Size	430mm, 650mm, 540mm
Wire Rope Dia. Capacity	1/16", 5/64", 3/32", 7/64", 1/8", 5/32", 3/16"
Extensive Use	It's widely used in railing, decking, DIY balustrade, clotheslines, outdoor shades, or hanging string lights in the garden.

Specifications of CLGR® Bench Swager 1/16 inch to 3/16 inch Drop Forged

Part No.	Overall Length	Wire Rope Dia. Capacity								Measurement	Pcs/Ctn	Weight
Part No.	(mm)	mm (inch)								cm	Pcs/Ctn	kg
		①		②		③		④	⑤
CRBENCHSW430	430	1.5	2.0	2.5	2.8	3.0	3.5			46×40×26.5	20	22
CRBENCHSW430	430	(1/16”	5/64”	3/32”	7/64”	1/8”	-)			46×40×26.5	20	22
CRBENCHSW650	650	1.5	2	2.5	2.8	3.0	3.5	4.0	5.0	67×32×16.5	6	16
CRBENCHSW650	650	(1/16”	5/64”	3/32”	7/64”	1/8”	-	5/32”	3/16”)	67×32×16.5	6	16
CRBENCHSW540	540	1.5	2	2.5	2.8	3.0	3.5	4.0	5.0	57.5×33×21	2	14
CRBENCHSW540	540	(1/16”	5/64”	3/32”	7/64”	1/8”	-)	5/32”	3/16”)	57.5×33×21	2	14
