CLGR® Stainless Steel Swivel Eye with Safety Pin Double Wheel Pulleys

Name: CLGR® Stainless Steel Swivel Eye with Safety Pin Double Wheel Pulleys
Brand: CLGR®

CLGR® Stainless Steel Swivel Eye with Safety Pin Double Wheel Pulleys, also known as Stainless Steel Double Pulley Block Wheel Swivel Eye Rope, Double Swivel Toggle Eye.

It comes with two sheaves that lift right out once you pull the split pin. Both wheels sit on a swivel eye that turns freely to keep your line running true, without snags or twists getting in the way.

Built from stainless steel, this double pulley holds up well in marine and industrial settings where moisture and salt. The two-sheave design gives you extra load capacity and better mechanical advantage when you need to handle heavier lifts.

Available sheave sizes: 25mm (fits 6mm wire rope), 32mm (fits 8mm), and 50mm (fits 10mm). Custom options on request.

To Get A Quote >

Overview of CLGR® Stainless Steel Swivel Eye with Safety Pin Double Wheel Pulleys

Brand	CLGR®
Material Options	AISI 304 (standard) / AISI 316 (marine grade)
Surface Treatment	High-polish
Diameter	25mm, 32mm, 50mm
Recommended Rope Size	6mm, 8mm, 10mm diameter
Origin	China

Specification of CLGR® Stainless Steel Swivel Eye with Safety Pin Double Wheel Pulleys

Drawing of CLGR® Stainless Steel Swivel Eye Double Wheel Pulleys China Manufacturer

Part No.	D (mm)	RopeΦ (mm)	L (mm)	W (mm)	Min.BL (KN)
CRSS-SEPSPD-25	25	6	83	15	13,9
CRSS-SEPSPD-32	32	8	97	16	13,9
CRSS-SEPSPD-50	50	10	127	20	21,8

CLGR® Are Expecting Your Inquiry!

We design, manufacture and distribute products and provide services for lifting and material handling applications, the construction metal industry, the trawl industry and the yacht accessories industry.
