CLGR® Stainless Steel Door Hinge 100*114mm

Name: CLGR® Stainless Steel Door Hinge 100*114mm
Brand: CLGR®

CLGR® Stainless Steel Door Hinge (100×114mm), also known as Flat Mounting Exposed Hinge, is a robust and reliable hardware component designed for heavy-duty door applications in industrial, mechanical, and electrical enclosures.

Made from stainless steel with a brushed finish, it offers excellent corrosion resistance and a clean, professional appearance.

This hinge is specifically suited for use on GCS cabinets, GCK cabinets, high and low voltage switchgear, and other equipment enclosures where secure and frequent door operation is required. Its sturdy construction ensures high load-bearing capacity, wear resistance, and smooth, effortless opening and closing over extended use.

Designed for long-term performance, this hinge resists deformation and breakage, making it a dependable choice for both factory installations and field maintenance applications.

To Get A Quote >

13.CLGR® Stainless Steel Door Hinge 100114mm

Overview of CLGR® Stainless Steel Door Hinge 100*114mm

Brand	CLGR®
Product Name	Stainless Steel Door Hinge
Model Size	100 × 114 mm
Material	316 Stainless Steel
Surface Finish	Brushed
Application	Industrial enclosures, mechanical cabinets, electrical switchgear
Suitable For	GCS cabinets, GCK cabinets, high/low voltage switchgear, equipment access doors
Installation	Surface mount / screw fixing
Durability	Long service life, resists breakage and deformation

Specification of CLGR® Stainless Steel Door Hinge 100*114mm

Drawing of CLGR® Stainless Steel Door Hinge 100*114mm

Part No.	SIZE	A	B	C	D	E	F	G	H	WT (KG)
CRSS-DH517-114	100*114	114.0	100.0	34.0	80.0	34.0	6.5	6.0	28.0	0.531
