CLGR® Grade 70 Clevis Lug Link AS NZS 4344

Name: CLGR® Grade 70 Clevis Lug Link AS NZS 4344
Brand: CLGR®

CLGR® Grade 70 Clevis Lug Link AS/NZS 4344, also known as G70 Lug Link Clevis, and Clevis Choke Ring.

The Clevis Lug Links combined with Grade 70 Chain are an effective way to restrain heavy loads for transport operations with the benefit of a loop to use as a tow or anchor point, Commonly used for drag Chain applications.

Manufactured from dropped forged steel quenched and tempered and gold zinc plated.

Marked with Chain size, lashing capacity, grade. Sizes available from 8 to 13mm.

Comply with AS 4344, Batch Test Certificate available upon request.

To Get A Quote >

Overview of CLGR® Grade 70 Clevis Lug Link AS/NZS 4344

Brand	CLGR®
Standard	Clevis lug link Grade 70 complies to AS/NZS 4344 standard
Grade	Grade 70
Material	Superior Alloy Steel
Processing	Forged
Finish	Gold zinc plated, Hot Dip Galvanized
Size	8mm, 10mm, 13mm.
Country of Origin	China

Specifications of CLGR® Grade 70 Clevis Lug Link AS/NZS 4344

CLGR® Grade 70 Clevis Lug Link AS/NZS 4344 China Supplier

Part No.	Size	N.W	L.C.	B.L	B±1.5	A±0.5	D±2	K±2	L±2
Part No.	Size	KG			mm
CRCLL08	8mm	0.555	3800	7600	35	12	86	108	142
CRCLL10	10mm	0.63	6000	12000	36	13.5	95	119	156
CRCLL13	13mm	0.93	9000	18000	48.5	18	100	132	175

LC=LOAD CAPACITY

BL=BREAKAGE LOAD

BL=LC x 2 TIMES

Safety Note: Grade 70 should ONLY be used for lashing and dragging, not for lifting.
