CLGR® 1x37 Steel Wire Rope Galvanized

Name: CLGR® 1x37 Steel Wire Rope Galvanized
Brand: CLGR®

LGRIG® 1×37 Galvanized Steel Wire Rope is manufactured in strict accordance with DIN 3054 standard, featuring a single-layer 1×37 strand construction.

This rope is twisted in three operations, with a structure consisting of three layers of wires wound around a central wire (1-6/12/18 configuration), delivering greater flexibility for applications requiring frequent bending.

Made of high carbon steel with hot-dip galvanizing, it ensures a superb tensile strength of 1770 N/mm² while providing reliable corrosion resistance.

With its excellent flexibility, this wire rope is specifically designed for tension-only applications, commonly used in industrial equipment, automotive brake and accelerator cables, tension/suction cables, and suspension cables.

Note: Not intended for aircraft use, not certified to MIL-W-83420.

To Get A Quote >

Overview of CLGR® 1x37 Steel Wire Rope Galvanized

Brand	CLGR®
Rope Type	Single strand wire rope
Construction	1x37(1+6+12+18)
Standard	DIN3054
Finish	Galvanized
Application	Large-scale field structure parts, suspension cables, tension tower.
Country of Origin	China

Specifications of CLGR® 1x37 Steel Wire Rope Galvanized

Part No.	Nominal Dia.	Approx Weight	Nominal Tensile Strength(MPa)
	Nominal Dia.	Approx Weight	1570	1770
	mm	kg/100m	MBS(kN)
D1X37K014	1.4mm	0.98	1.51	1.7
D1X37K021	2.1mm	2.21	3.39	3.82
D1X37K028	2.8mm	3.93	6.03	6.8
D1X37K035	3.5mm	6.14	9.42	10.6
D1X37K042	4.2mm	8.84	13.6	15.3
D1X37K049	4.9mm	12	18.5	20.8
D1X37K056	5.6mm	15.7	24.1	27.2
D1X37K063	6.3mm	19.9	30.5	34.4
D1X37K070	7mm	24.5	37.7	42.5
D1X37K077	7.7mm	29.7	45.6	51.4
D1X37K084	8.4mm	35.4	54.3	61.2
D1X37K091	9.1mm	41.5	63.7	71.8
D1X37K098	9.8mm	48.1	73.9	83.3
D1X37K105	10.5mm	55.2	84.8	95.6
D1X37K110	11mm	60.6	93.1	105
D1X37K120	12mm	72.1	111	125
