CLGR® 8-Shape Ring Alloy Steel

Name: CLGR® 8-Shape Ring Alloy Steel
Brand: CLGR®

CLGR® 8-Shape Ring Alloy Steel, also known as 8-Type Ring and F8 Ring.

The unique 8-shaped design with an eyelet of the CLGR® allows for secure connections with ropes, chains, or other rigging equipment.

The figure-eight shape helps control movement and reduces the chances of abrasion or cutting caused by traditional split rings.

Ideal for demanding applications, these rings are crafted from super alloy steel with power coated for superior strength and corrosion resistance in saltwater environments.

To Get A Quote >

CLGR® 8 Shape Ring Alloy Steel China Manufacturer

CLGR® 8 Shape Ring Alloy Steel China Supplier

 

Overview of CLGR® 8-Shape Ring Alloy Steel

Brand	CLGR®
Material	Super Alloy Steel
Safety Factor	4: 1
Processing	Forged / Quenched and Tempered
Finish	Powder Coated
WLL	8T
Tips	Color Code: Customized according to customers' requirements
Note	Never exceed Working Load Limit
Country of Origin	China

Specification of CLGR® 8-Shape Ring Alloy Steel

Part No.	S.W.L. (ton)	B.T.L. (ton)	Dimensions(mm)					Weight (kg)
Part No.	S.W.L. (ton)	B.T.L. (ton)	A	B	C	D	E	Weight (kg)
CRP08TR28	8	32	233.5	178	124	68	28	3.55
CRP12TR32	12	48	274	209	149	84	32	4.2

CLGR® Are Expecting Your Inquiry!

We design, manufacture and distribute products and provide services for lifting and material handling applications, the construction metal industry, the trawl industry and the yacht accessories industry.
