Our 6×7+IWS steel wire rope with a Steel Core is the ideal solution where excellent wear resistance is critical.
Constructed with six strands of seven wires, it delivers outstanding durability and abrasion protection, suitable for winch lines, garage door cables, and various general-purpose tie-down applications. For enhanced corrosion resistance, we offer a hot-dip galvanized option.
In addition, our 6×7 FC (Fiber Core) version is available for applications that demand higher crush resistance than standard fiber core ropes can provide.
Brand | CLGR® |
Construction | 6×7+IWS |
Material | Steel |
| Treatment | Galvanized/ Bright |
Standard | EN 12385-4 (formly DIN3055) |
Country of Origin | China |
Part No | Nominal Dia. | Approx. Weight | MBS(kN) | |
mm | kg/100m | 1570/mm² | 1770/mm² | |
6x7iws03 | 3 | 3.65 | 5.48 | 5.71 |
6x7iws04 | 4 | 6.50 | 9.75 | 10.2 |
6x7iws05 | 5 | 10.15 | 12.23 | 22.9 |
6x7iws06 | 6 | 14.62 | 21.9 | 40.6 |
6x7iws08 | 8 | 25.98 | 36.1 | 63.5 |
6x7iws10 | 10 | 40.60 | 56.3 | 91.5 |
6x7iws12 | 12 | 58.46 | 81.1 | — |
6x7iws14 | 14 | 79.58 | 110 | — |
6x7iws16 | 16 | 103.94 | 144 | — |
6x7iws18 | 18 | 131.54 | 183 | — |
6x7iws20 | 20 | 162.40 | 225 | — |
