CLGR® Wire Lock Pin Galvanized Steel

Name: CLGR® Wire Lock Pin Galvanized Steel
Brand: CLGR®

CLGR® Wire Lock Pin Galvanized Steel are also known as Quick-Release Wire Lock Pins PTO Pins, Square Wire Lock Pin, Snapper Pins, Hitch Pins and Quick Pins.

Combining a pin and cotter into a single secure assembly, wire lock pins feature a wire loop that can be pulled over the pin’s end to either lock it firmly in position or release it for removal.

As a one piece quick-locking pin, they eliminate the risk of cotter pin loss and are compatible with most quick-release setups.

Unlike clevis pins paired with cotters, these quick-locking pins do not require separate cotter pins and allow for much faster operation. Additionally, most sizes of these wire lock pins come with either a round handle or a square handle to suit different user preferences.

The wire lock pins are available in carbon steel or stainless steel (grade 304/316) to meet various application needs.

Customers can choose between clear galvanized coating or a stainless steel finish, ensuring durability and resistance to corrosion.

To Get A Quote >

Overview of CLGR® Wire Lock Pin Galvanized Steel

Brand	CLGR®
Material	Superior Carbon Steel; Stainless Steel AISI304 or AISI316 is also available
Processing	Stamped
Finish	Electric Galvanized
Size	1/4”×1-3/8”, 1/4”×1-3/4”, 1/4”×2-1/4”, 1/4”×2-1/2”, 1/4”×2-1/2”, 5/16”×1-3/8”, 5/16”×1-3/4”, 5/16”×2-1/4”, 5/16”×2-1/2”, 5/16”×2-1/2”, 5/16”×3”, 3/8”×1-3/8”, 3/8”×1-3/4”, 3/8”×2-1/4”, 3/8”×2-1/2”, 3/8”×2-1/2”, 3/8”×3”, 1/2”×3”
Tips	Special specification and marks can be made according to customers’ requirements

Specifications of CLGR® Wire Lock Pin Galvanized Steel

Part No.	Pin dia	Shank length	Usable length	Wire dia	Wire clearance	Head dia	Handle type	Pcs/bag	Wgt(lbs)/bag
CRWLPO10	1/4	1 - 5/8	1 - 3/8	0.091	1 - 5/8	9/16	RD	25	2
CRWLPO12	1/4	2	1 - 3/4	0.091	1 - 9/16	9/16	RD	25	2
CRWLPO13	1/4	2 - 1/2	2 - 1/4	0.091	1 - 5/8	9/16	SQ	25	2
CRWLPO14	1/4	2 - 3/4	2 - 1/2	0.091	1 - 3/4	9/16	SQ	25	2
CRWLPO16	1/4	2 - 3/4	2 - 1/2	0.091	1 - 3/4	9/16	RD	25	2
CRWLPO20	5/16	1 - 5/8	1 - 3/8	0.091	1 - 9/16	5/8	RD	25	2
CRWLPO22	5/16	2	1 - 3/4	0.091	1 - 1/2	5/8	RD	25	2
CRWLPO23	5/16	2 - 1/2	2 - 1/4	0.091	1 - 9/16	5/8	SQ	25	3
CRWLPO24	5/16	2 - 3/4	2 - 1/2	0.091	1 - 11/16	5/8	SQ	25	3
CRWLPO26	5/16	2 - 3/4	2 - 1/2	0.091	1 - 11/16	5/8	RD	25	3
CRWLPO28	5/16	3 - 1/4	3	0.091	1 - 11/16	5/8	SQ	25	4
CRWLPO30	3/8	1 - 5/8	1 - 3/8	0.091	1 - 1/2	5/8	RD	25	3
CRWLPO32	3/8	2	1 - 3/4	0.091	1 - 7/16	5/8	RD	25	3
CRWLPO34	3/8	2 - 1/2	2 - 1/4	0.091	1 - 1/2	5/8	SQ	25	4
CRWLPO36	3/8	2 - 3/4	2 - 1/2	0.091	1 - 5/8	5/8	SQ	25	4
CRWLPO38	3/8	2 - 3/4	2 - 1/2	0.091	1 - 5/8	5/8	RD	25	4
CRWLPO39	3/8	3 - 1/4	3	0.091	1 - 5/8	5/8	SQ	25	4
CRWLPO40	1/2	3 - 1/2	3	0.125	1 - 7/16	3/4	SQ	10	3
